2 Waves 3 Waves Guardrail Roll Forming Machine

Email: info@suhangmachine.com

Tel: 008613606193016

Whatsapp: 8613606193016

description1

Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout

Description

Specification

A guardrail is a safety barrier designed to prevent vehicles from veering off the road or crashing into dangerous areas, such as cliffs, embankments, or other hazards. They’re commonly found on highways, bridges, and curves to help protect drivers and passengers. Guardrails come in various forms and materials, including metal, concrete, and wood, and are engineered to absorb and redirect the force of a collision to minimize damage and injuries.

There are 2 waves( W-beam), 3 Waves(thrie-beam), we can make 2 waves, 3 waves in one machine. Usually, the thickness is 2-4mm.

Techncial Data:

main motor power: 22 kw
station: adopt cast iron HT50
Decelerating motor: made in Shanghai or Changzhou
drive: gearbox driving
main shaft dia: ￠120mm material: 45﹟forge steel
roller material: GCR15 quenched 58°-62°,chromed
roll station:14stations
roller thickness: 2mm-3mm
Timing by transducer:5m--7m/min(including punching)
Transducer: Panasonic made in Japan. 415V 50HZ, 3phases
Computer: PLC
Computer operating panel: touching screen

Machine List:

5 Tons Hydraulic Decoiler	1 set
Leveling	1 set
Hydraulic Punching	2 sets
Main Roll Forming Machine	1 set
Hydraulic Cutting	1 set
Output table	1 unit
Control box	1 unit
Spare Part	1 package

Profile Drawing:

Finished Products:

Application:

Highways and Roads: The primary application is in the construction and maintenance of highways and roads. Guardrails help to prevent vehicles from veering off the road, especially on curves, bridges, and elevated sections.

Bridges and Overpasses: Guardrails are installed on bridges and overpasses to prevent vehicles from falling off the edge and to protect pedestrians and other infrastructure.

Parking Lots: In parking lots, guardrails are used to delineate parking spaces, protect pedestrians, and prevent vehicles from damaging property or other vehicles.

Railways: Guardrails can be used alongside railway tracks to keep vehicles and pedestrians at a safe distance from the tracks.

Industrial Facilities: In industrial settings, guardrails are used to protect workers from falling into hazardous areas or machinery. They are also used to safeguard equipment and infrastructure.

Commercial and Residential Properties: Guardrails are used around properties, including in commercial areas, residential buildings, and recreational facilities, to enhance safety.

Sports Facilities: At sports venues, guardrails can be used to protect spectators and separate different areas of the facility.
