Roll forming machine:
Roll Forming Machine: RF-RP
Rolling Speed : 10-12m/min(cutting time is not include)
Steel sheet Thickness: 0.4-0.8mm color painted sheetsand galvanized steel
Control System: PLC
Roller Stations: upper/ down layer is about 14 stations
Roller Material : 45# forge steel, coated with chrome
Shaft Material and DIA: ¢75mm,material is 45# forge steel, Chrome with quenching
Main Motor Power: 5.5kw
Hydraulic Pressure: 12Mpa
Tolerance: +1.5mm
Power supplier:380V, 50HZ,3 phase
Way Of Drive:1.2 inch single chain
Color Of The Machine :blue
The size of the forming machine:About 6000*1500*1000mm
Machine List:
5 tons passive de-coiler |
1 set |
Feeding with guide |
1 set |
Main roll forming machine |
1 set |
PLC Control box |
1 unit |
Hydraulic station |
1 unit |
Hydraulic cutting |
1 unit |
Out tables |
2 units |
Safety cover |
1 set |
Our display screen is touch screen, not text touch screen.
Sussman roll forming system: We will make the hand wheels at the feeding device to adjust feeding width, and we also make the wheels with the numbers then you know how to adjust right and left sides, also we made the rulers on the bedding, you can adjust the profile height and width according to the rulers.
Screw with numbers is to adjust material thickness easily, also with protecting cap also add laminating film device and felt to make the board flatter and smoother without scratches.
The machine is equipped with a detection switch device, in case of emergency, emergency alarm, stop operation.
