Klip Lock 700 730 410 Roof Sheet Roll Forming Machine

description1
Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Description
Specification

Klip Lok roofing is a strong and durable long length roof (or wall) cladding. As the name suggests, Klip Lok is secured with concealed fasteners and fixed clips. This allows the sheets to be secured without being punctured. This cladding is ideal for low pitched and flat roofs as well as vertical and horizontal ribbed walling. As there are no exposed fasteners, your roof will have a smooth, clean look. Klip Lok roofs are ideal for anyone looking for an easy to install material that is cost-effective.

Technical Data:

Rolling Speed : 10-12m/min(cutting time is not include)

Steel sheet Thickness: 0.3-0.7mm color painted sheets

Coil width 914mm, effective width 720mm

Control System: PLC Siemens

Roller Stations: about 20 stations

Roller Material : 45# forge steel, coated with chrome

Shaft Material and DIA: ¢75mm,material is 45# forge steel, Chrome with quenching

Main Motor Power: 7.5kw

Hydraulic Pressure: 12Mpa

Material Of The Stations: Wall plate thickness 16mm

Tolerance: +1.5mm

Power supplier: 380V, 50HZ,3 phases

Way Of Drive:1 inch single chain

Color Of The Machine :customer’s need)

The size of the forming machine:7000*1500*1000mm

Machine weight: about 7 tons

Machine List:

5 tons passive de-coiler

1 set

Main roll forming machine

1 set

Control box

1 unit

Hydraulic stop cutting

1 unit

Passive output tables

2 units

Spare part

1 package

Safety cover

1 unit

Profile Drawings:

Profile Drawing:

Application:

1, Stiffener ribs on baseplate add formidable strength, specifically over the goose-neck;

2, Full width engagement on the goose-neck male joint;

3, 5 fastening points for stability, particularly over blanket insulation;

4, Engineer-designed geometry of anchor unit f or optimal performance under high wind loads and foot traffic;

5, Entire clip is manufactured from Aluminium – Zinc coated steel for compatibility with sheeting.
