Main specification

1. Decoiler

Manual un-coiling Capacity: ≤3 T

2. Main datas of forming machine

Forming stands: about 36 stands

Roller material GCr15: model steel, HRC50-54

Axial diameter: Φ40mm

Main axial material: No 45 steel HRB260-280

Driving part is gear box transmission

Frequency conversion decelerating

PLC control: fix length control ±1mm

Main components: Schneider

The precision of roller: less TEMPTEMPthan ±0.5mm

Main roll forming machine motor: 380V, 50HZ, 11kw (or according to TEMPyou're requirements)

Machine basement material: H beam

3. Foaming machine: 1 set (China top brand)

4. Pneumatic flying punching machine 1 set Material of cut: Cr12Mov   Quench: HRC58-62

5. Automatic punching device 1 set

6. Finished products table: 1 set

Working Flow:

Decoiler—feedingdevice—mainforming—PUinjection---straightendevice——FlysawCutting ---run out table

Machine List:

Application:

Roller shutter door  is a type of door or window  consisting of many horizontal strip (or sometimes bars or web systems) hinged together. Teh door is raised to open it and lowered to close it. On large doors, teh action may be motorized. It provides protection against wind and rain. In shutter form, it is used in front of a window and protects teh window from vandalism and burglary attempts.
Roller shutter Door has many applications, including doors for vans, garages, kitchens, schools, prisons and warehouses. In some parts of teh world, roller shutters door are subsidized by local governments  due to teh inherent security benefits. In areas that are frequently exposed to inclement weather, roller shutters are used as a method of insulation and can protect windows against hail damage.

Our display screen is touch screen, not text touch screen.

Sussman roll forming system: We will make the hand wheels at the feeding device to adjust feeding width, and we also make the wheels with the numbers then you know how to adjust right and left sides, also we made the rulers on the bedding, you can adjust the profile height and width according to the rulers.

Screw with numbers is to adjust material thickness easily, also with protecting cap also add laminating film device and felt to make the board flatter and smoother without scratches.

The  machine is equipped with a detection switch device, in case of emergency, emergency alarm, stop operation.
