Selflock 700mm Roof Metal Sheet Boltless Roll Forming Machine

description1
Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Specification
Specification

1.Passive uncoiler 5 ton

2.Main motor power:7.5KW

3.Motor power of hydraulic station:4KW

4.Forming station: about 18 stands

5.Main machine size:8.5 m×1.2m×1.25m

6.Forming speed: 10m/min

7.Diameter of roller shaft:¢76mm

8.Raw material width: as profile

9.Roller surface coating with chrome:single face≥0.05mm

10.Forming thickness:0.3-0.8mm

11.profile according to GB/T12755-91 standards

12.material of cutting blade: Cr12

13.frequency: Delta

14. Computer (PLC)



Working Flow:

uncoiling→guide feeding→roll forming→cutting after set length→output

Profile drawing

Application

Boltless System LOCK700-40
Have a high curl and a wide belly thus increasing the batting distance more. Makes the structure economical - Fixing the sheet with the innovation of locking pin 3 in 1 "Superlock 40", which makes it easy to install, locks tightly, closely and is strong

Variety of profiles which suitable for roofing, walling and ceiling application. Due to strength, profile ability for long support spacing
Flexible to curve Lightweight, easy to install, and time saving
Boltless system (Concealed-fixing method) is suitable for applications
Available for straight sheet, curved or convex-concave curve
Rolled-form from High-tensile steel, min: yield strengths are G550 (550MPa) or G300 (300MPa), aluminum/zinc alloy-coated steel and clean colorbond prepainted steel



Optional Configuration For Your Choice
  • Decolier
    Double Heads Decoiler
    A type decoiler
    Manual Decoiler
    Hydraulic Decoiler


  • Structure
    Wall panel
    Torri Structure
    Cast Iron

  • Drive
    Chain
    Gear
    Gearbox
    Couplings Gearbox


  • Cooling
    Water cooling
    Fan cooling

  • Punching
    Hydraulic punching
    Hydraulic press
    Punching press

  • Cutting
    Hydraulic stop cutting
    Servo Following Cutting
    Stop Saw cutting
    Fly saw cutting


  • Out table
    Manual table
    Simple pneumatic table
    Automatic stacker
    Magnetic stacker


  • Other
    Cassette
    Plastic film
    Fleece devce
    Pre-cutting


What is Sussman's machine different from other suppliers?
The price of Sussman's roll forming machines is a little higher than other suppliers'. Let me explain about our machines difference:
Sussman machine design: it is unit one, which means the control box and the hydraulic station are all put under the machine frame, when you get the machine, no need to assemble and connect the complicate cable of the machine, you only need to connect one main cable, then the machine is working. it saves more time and space.

Our display screen is touch screen, not text touch screen.

Sussman Machinery



Other suppliers

Sussman Processing technology: Sussman rollers is through grinding, quenched, chroming,finish machining,polishing,coated with chrome 0.05mm, all rollers are shiny, stronger and avoid rust.etc to make stronger, the roll forming machine is more robust and easier to use.  The metal sheet produced by our machine is always flat and perfect profiles., because in the design and during the machining process, we always control the force for the metal sheet, it does not damage the sheet surface and comes out perfect profile. And we use the German application COPRA, to imitate the situation in 3D and ensure the perfect profile.
Sussman Machinery

Other suppliers

Sussman roll forming system

Sussman roll forming system: We will make the hand wheels at the feeding device to adjust feeding width, and we also make the wheels with the numbers then you know how to adjust right and left sides, also we made the rulers on the bedding, you can adjust the profile height and width according to the rulers.

Screw with numbers is to adjust material thickness easily, also with protecting cap also add laminating film device and felt to make the board flatter and smoother without scratches.

The  machine is equipped with a detection switch device, in case of emergency, emergency alarm, stop operation.




Sussman Machinery's safety cover
The whole equipment is in accordance with the requirements of CE standards, and the entire body and transmission parts are covered to protect the safety of workers.
Sussman Machinery
Other suppliers

Roof tile box
Sussman Machinery
Other suppliers

Hydraulic cutting
Sussman Machinery
Other suppliers
